New design 40t/h portable aspalt mixing plant on sale

FOB Reference Price:Get Latest Price
US $10,000-20,000 / Sets | 1 Set/Sets High quality YDHB40 asphalt concrete mixing plant mobile asphalt (Min. Order)
Model Number:
YDHB40
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Henan, China (Mainland)
Brand Name:
AIMIX
Voltage:
220V/380V-50Hz
Power(W):
60KW
Dimension(L*W*H):
30m*16m*6m
Weight:
30T
Certification:
ISO.CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
New design 40t/h portable aspalt mixing plant on sale
Capacity:
40t/h
asphalt tank valume:
10m3
oil consumption:
5.5 to 7 kg/t
General installed power:
75KW
Burner:
Oil/gas/coal
Mixer:
SIEMENS motors and reduction
Control system:
PLC
Color:
Customizable
Application:
construction industry
Supply Ability
Supply Ability:
1000 Set/Sets per Year
Packaging & Delivery
Packaging Details
standard package
Port
lianyungang
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 20 To be negotiated

New design 40t/h portable aspalt mixing plant on sale

Product Description

New design 40t/h portable aspalt mixing plant are small-type plant which could be widely used in expressway or highway build and maintenance, and is especially suitable for short term or medium term projects to produce asphalt, modified asphalt, colored asphalt.

Main feature:

1,The module design for handling, It takes only few days to install, no need of large-ton cranes, no cutting and no welding.

2,Unique design stirring blade, driven the mixing tank makes mixing easier, more reliable and efficient;

3,The use of imported vibration motor driven vibrating screen, greatly improving the efficiency, but also reduces the failure rate of the equipment;

4,Bag dust placed in the drying state, placed above the drum to reduce heat loss, save space and fuel;

5,The bottom of the warehouse structure relative to the structure, thus greatly reducing the area occupied by the equipment, while eliminating the finished product lanes to enhance the space, reducing the equipment failure rate.

New design 40t/h portable aspalt mixing plant on sale

Technology parameter



Model

Productivity (T/h)

General installed power(kw)

YDHB20

20

40

YDHB25

25

50

YDHB40

40

75

YDHB60

60

123

YDHB80

80

140

Product Display

  Our plant includes aggregate feeding system, aggregate heating system, screening system, weight-control system, mixing system, bitumen supplying system and Control system, etc.

 New design 40t/h portable aspalt mixing plant on sale



New design 40t/h portable aspalt mixing plant on sale



Company Information

History:

With more than 30 years development, our company has become one of the leading professional manufacturers and exporters of Construction Machinery in China. Till now, the factory area covering reaches 120,000m2 and have about 1000 person, including engineers, workers, sales, and service people.

Certificates:

We have got certificate ISO9001:2000 and passed SGS test. At present, our products are popular at home and abroad.

Our Markets:

Holding high quality products and honest operation as tenets, we have developed international market very well, such as Russia, Southeast Asia, Central Asia, Mid-East, South Africa, America, etc, more than twenty countries and regions.

Exhibition show:

Our company participated in the exhibition in Indonesia in 2016, and obtain many coustomers' recogntion to establish long-term cooperative relations.
