JBS40-JS750 electric mini concrete pump machine concrete pump truck mercedes

FOB Reference Price:Get Latest Price
US $20,000-30,000 / Set | 1 Set/Sets JBS40-JS750 electric mini concrete pump machine concrete pump tr (Min. Order)
Supply Ability:
100 Set/Sets per Quarter JBS40-JS750 electric mini concrete pump machine concrete pump tr
Port:
qingdao
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Power Type:
Electric
Place of Origin:
Henan, China (Mainland)
Brand Name:
AIMIX
Model Number:
JBS40-JS750
Power(W):
30kw
Weight:
3000KG
Dimension(L*W*H):
4120*2100*2600mm
Certification:
ISO CE
Warranty:
12 Months
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
electric mini concrete pump machine concrete pump truck mercedes
Application:
Concrete Placing
Type:
S- Valve
Max Exit Pressure:
10Mpa
productivity:
40m3/h
Hydraulic Oil Tank Volume:
750L
Exit Diameter:
100mm
Motor Power:
47.55kw
Max Aggregate Size:
30mm
Color:
Customers' Requirement
Packaging & Delivery
Packaging Details
one 40HQ can load one set concrete mixer pump
Delivery Time
7 days after received the deposit

JBS40-JS750 electric mini concrete pump machine concrete pump truck mercedes

Product Description

JBS40-JS750 electric mini concrete pump machine concrete pump truck mercedes is a type of fully automated construction operating system machine, which set feeding, mixing and high pressure pump as one of the concrete mixer pump. About mixing pump, easy operation , stable performance, easy to move.

Compared with tradition concrete mixer pump, JBS40-JS750 electric concrete pump with mixer machine has higher productivity. JS750 concrete mixer machine adopt twin-shaft blade, the material can be mixed more evenly in short time.







Main features

1.Perfect combination of the concrete mixer and pump , saving rack weight

2.Small concrete pump equipped with a mixer to facilitate rural haulage, high efficiency;

3.Save worker costs, reduce labor intensity;

4.Smaller power, taking into account the carrying capacity of the rural power grid;

5.Easy to operate, with the remote control operation stir the pump, more safety and convenient.

6.The use of double-cylinder full hydraulic pumping system, which can transport conventional aggregate or gravel concrete, stable performance, safe and reliable.

Main parts



Technology parameter





Items

Unit

JBS40-JS500

JBS40-JS750

Max Theoretical Conveying Capacity

m3/h

40

40

Max Exit Pressure

M pa

11

11

Concrete Cylinder bore * stroke

mm

160*1200

160*1200

Main Oil Cylinder bore * stroke

mm

100/70*1200

100/70*1200

Hydraulic Oil Tank Volume

L

350

350

Exit Diameter

mm

150

150

Conveying Pipe Inner Diameter

mm

125/150

125/150

Motor Power

KW

70.1

83.6

MaxAggregate Size

mm

40

40

Max Horizontal Conveying Distance

M

600

600

Max Vertical Conveying Distance

M

150

150

Mixer Model



JS500

JS750

Input Volume

L

750

1200

Output Volume

L

500

750

Drum Diameter

mm

1440

1440

Mier productivity

M3/h

25

35

Outline Dimension (L*W*H)

mm

5100*2250*2860

5200*2250*3110

Weight

Kg

5000

6500

Our Services



Successful Cases

We exported to JBS40-JS750 electric concrete pump with mixer machine  to Indonesia, fristly, our coustomers visited our factory, and be satisfied with our product's quality .Thanks to our reasonable price and high quality products, the customer signed a purchase contract with us on the spot.

these are some visiting and packing photos as follow:



Company Information

History:

With more than 30 years development, our company has become one of the leading professional manufacturers and exporters of Construction Machinery in China. Till now, the factory area covering reaches 120,000m2 and have about 1000 person, including engineers, workers, sales, and service people.

Certificates:

We have got certificate ISO9001:2000 and passed SGS test. At present, our products are popular at home and abroad.

Our Markets:

Holding high quality products and honest operation as tenets, we have developed international market very well, such as Russia, Southeast Asia, Central Asia, Mid-East, South Africa, America, etc, more than twenty countries and regions.

Exhibition show:

Our company participated in the exhibition in Indonesia in 2016, and obtain many coustomers' recogntion to establish long-term cooperative relations.





If you have any idea or request, please contact us,

JBS40-JS750 electric mini concrete pump machine concrete pump truck mercedes!

we can provide electric and diesel concrte mixer pump!
