40m3 small concrete mobile pump ready mix concrete pump price

FOB Reference Price:Get Latest Price
US $1,000-5,000 / Sets | 1 Set/Sets 30m3 small concrete mobile pump ready mix concrete pump price (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Power Type:
Diesel
Place of Origin:
Henan, China (Mainland)
Brand Name:
AIMIX
Model Number:
HBT-40SR
Power(W):
56kw
Weight:
4500kg
Dimension(L*W*H):
5500*2000*2350 mm
Certification:
ISO CE
Product name:
40m3 small concrete mobile pump ready mix concrete pump price
Capacity:
40m3/h
Feeding Height:
1350mm
Hopper Capacity:
0.35m3/h
Max. Pumping Pressure:
8M pa
Max. Vertical Conveying Distance:
100m
Max. Conveying Distance:
450m
Max.Aggregate Diameter:
40mm
Application:
Construction Engineering
Color:
Customers' Requirement
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Supply Ability
Supply Ability:
100 Set/Sets per Month 30m3 small concrete mobile pump ready mix concrete pump price
Packaging & Delivery
Packaging Details
standard packing
Port
China main port
Lead Time :
within 15 days after advanced payment

30m3 small concrete mobile pump ready mix concrete pump price

Product Description

30m3 small concrete mobile pump ready mix concrete pump have been widely used in many construction areas such as Water conservancy, Electricity,Railway, Highway,Tunnel, Mine, National Defense, etc.They have also been exported to many countries and gotan excellent reputation .

Certification:

40m3 hydraulic vertical concreting pumps concrete pumps manufacturers have passed BV and ISO9001 International Quality System Certification and the mining concrete pumps have passed the Safety Certificate of Approval for Mining Products.





Technology parameter



Item

XHBT-20SR

XHBT-30SR

HBT-40SR

Max. Theoretical Throughput (m3/h)

20

30

40

Max. Pumping Pressure (M pa)

11

11

8

Max. Theoretical Vertical Conveying Distance (m)

160

160

100

Max. TheoreticalHorizontalConveying Distance (m)

600

600

450

Max.Aggregate Diameter (mm)

30

30

40

Slump (cm)

12-23

12-23

12-23

Conveying Pipe Radius (mm)

100A/80A

100A/80A

100A/80A

Conveying Cylinder Bore X Piston Stroke (mm)

140×1000

140×1000

180×1200

Hydraulic Oil Tank Capacity (L)

350

350

500

Feeding Height (mm)

1100

1200

1350

Hopper Capacity (m3)

0.35

0.35

0.35

Diesel Motor Model

R4105D2

R4105D7

WEICHAI DEUTZ

Power of DieselMotor (kw

46

61.6

56

Dimension (Length x Width x Weight) (mm)

5000*1700*2100

4450*1680*1950

5500*2000*2350

 Total Weight (kg)

3000

3050

4400

Advantages

1.The use of dual-pump, double-loop open hydraulic system, the main pump oil and S valve swing oil circuit independent of each other, the system is simple, component life extension, higher reliability, and easy to fault diagnosis and exclusion

2.With anti-pump function, which will help eliminate the block failure, and a short time to stop waiting for material.

3. The use of advanced S pipe distribution valve, can automatically compensate for wear and tear, sealing performance.

4.The use of wear-resistant alloy glasses and floating cutting ring, long service life. Glasses up to a maximum life of more than 30,000 square meters.

6.Automatic centralized lubrication system to ensure that the operation of the machine to be effective lubrication.

Main parts

 Some parts of concrete pump photos:

Our Services
Company Information

History:

With more than 30 years development, our company has become one of the leading professional manufacturers and exporters of Construction Machinery in China. Till now, the factory area covering reaches 120,000m2 and have about 1000 person, including engineers, workers, sales, and service people.

Our Markets:

Holding high quality products and honest operation as tenets, we have developed international market very well, such as Russia, Southeast Asia, Central Asia, Mid-East, South Africa, America, etc, more than twenty countries and regions.

Exhibition show:

Our company participated in the exhibition in Indonesia in 2016, and obtain many coustomers' recogntion to establish long-term cooperative relations.



FAQ

Q1:Can you sent me some wearing parts?

A:Yes, For some common wearing parts,we will send you freely.

Q2: What is the delivery time?

A: 3-15days after receiving advance payment.

Q3:What paymet terms you use?

A:Usually the world most common used T/T,L/C ,etc

Q4: Can we put our logo on the machine?

A. Yes, it is available.  LOGO and color are usually as per customer's requirement.
