Quick Details

  • Condition: New
  • Power Type: Diesel
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: AIMIX
  • Model Number: XHBT-80SR
  • Power(W): 162Kw
  • Weight: 7600 Kg
  • Dimension(L*W*H): 6750*2160*2700mm
  • Certification: ISO CE
  • Warranty: 12 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Diesel 80m3 concrete pump in pakistan concrete pump dimensions cost
  • Type: S- Valve
  • Application: Construction industry
  • Hydraulic System: opened type
  • Hopper Capacity: 0.68m3
  • Hopper Height: 1450mm
  • Rated Rotate Speed: 1480r/min
  • Hydraulic Oil Tank Capacity: 580 L
  • Concrete Slump: 120-230 mm
  • Max Concrete Pumping Pressure: 16 Mpa

Packaging & Delivery

Packaging Details standard packing
Delivery Time within 15 days after advanced payment

Diesel 80m3 concrete pump in pakistan concrete pump dimensions cost

Product Description

Diesel 80m3 concrete pump in pakistan concrete pump dimensions driven by the diesel engine to produce hydraulic pressure, the use of hydraulic pressure to drive the cylinder to produce reciprocating motion, driven by the piston to complete the suction and pressure of concrete action.



Application:

Diesel 80m3 concrete pump in pakistan concrete pump dimensions applicable on fine stone concrete conveying, floor heating construction, tunnel and underground construction, mortar conveying, used as spray pump when installed with incidental spraying equipment, for concrete, mortar, refractory material and green soil spraying, applied for high-rise conveying, railway, tunnel, bridge construction and special applications, hydraulic power,mining and national defense.



Advantages



1.The use of dual-pump, double-loop open hydraulic system, the main pump oil and S valve swing oil circuit independent of each other, the system is simple, component life extension, higher reliability, and easy to fault diagnosis and exclusion

2.With anti-pump function, which will help eliminate the block failure, and a short time to stop waiting for material.

3. The use of advanced S pipe distribution valve, can automatically compensate for wear and tear, sealing performance.

4.The use of wear-resistant alloy glasses and floating cutting ring, long service life. Glasses up to a maximum life of more than 30,000 square meters.

5.Automatic centralized lubrication system to ensure that the operation of the machine to be effective lubrication.

6.With remote remote control, the operation more secure and convenient.

Technology parameter



Item

HBT-40SR

XHBT-60SR

XHBT-80SR

Max. Theoretical Throughput (m3/h)

40

60

80

Max. Pumping Pressure (M pa)

8

13

16

Max. Theoretical Vertical Conveying Distance (m)

100

280

300

Max. Theoretical Horizontal Conveying Distance (m)

450

1000

1200

Max.Aggregate Diameter (mm)

40

50

60

Slump (cm)

12-23

12-23

12-23

Conveying Pipe Radius (mm)

100A/80A

180

180

Conveying Cylinder Bore X Piston Stroke (mm)

180×1200

200*1600

200*1800

Hydraulic Oil Tank Capacity (L)

500

580

580

Feeding Height (mm)

1350

1400

1450

Hopper Capacity (m3)

0.35

0.68

0.68

Diesel Motor Model

WEICHAI DEUTZ

WEICHAI DEUTZ

WEICHAI DEUTZ

Power of Diesel Motor (kw)

56

90/112/130

162

Dimension (Length x Width x Weight) (mm)

5500*2000*2350

6000*2160*2600

6750*2160*2700

 Total Weight (kg)

4400

6480

7600





Main parts

 Concrete pump include of the mechanical system, cooling system, lubricate system, hydraulic system, etc.



Packaging & Shipping

 In 2016, we has exported concrete pump to Philippine. there are packing photos as follow:







Company Information



1.Set up in 1982, our company has more than 30 years experience in the production of construction equipment.

2.Covering space:more than 90,000m², floor area around 50,000 m² , skilled workers can guarantee the product quality and time of delivery.

3 with well-known brands of parts, quality assurance.

4 we have got praise many times by the government, our company has a CE certificate; passed the ISO9001 international quality system certification in 2001, assurance of product quality.

5.perfect team, Sound rules and regulations: professional e-business and document team department facilitates customer understanding of product information, saving customers customs declaration and transport time and money.

6.Our company participated in the exhibition in Indonesia in 2016, and obtain many coustomers' recogntion to establish long-term cooperative relations.







Diesel 80m3 concrete pump in pakistan concrete pump dimensions cost!

welcome to visit our factory!
