Quick Details

  • Condition: New
  • Power Type: Electric
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: AIMIX
  • Model Number: HBT-60
  • Power(W): 90kw
  • Weight: 6000kg
  • Dimension(L*W*H): 6000*2160*2600mm
  • Certification: ISO CE
  • Warranty: 12 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: Low price of concrete pump dimensions concrete pump for sale in korea
  • Type: S- Valve
  • Color: Customers' Requirement
  • capacity: 60m3/h
  • Max pressure: 13Mpa
  • Max. Aggregate size: 50mm
  • Hydraulic Oil Tank Capacity: 580L
  • Feeding Height: 1420mm
  • Max.Vertical Conveying Distance: 190m
  • Max.Horizontal Conveying Distance: 800m

Packaging & Delivery

Packaging Details standard package
Delivery Time Shipped in 5 days after payment

Low price of concrete pump dimensions concrete pump for sale in korea

Product Description

Low price of concrete pump dimensions concrete pump concrete pump machinery is composed of pump and pipe. Using of pressure, the concrete along the pipeline continuous transmission of machinery, mainly used in housing construction, bridges and tunnel construction.

 Feature:

1. Wireless remote control. Save the time and improve the efficiency.

2. Equipment swing cylinder to do the buffer system, reducing the impact on the hydraulic system, and increase of equipment life.

3. Anti-pump is in the boot state of the first withdrawal the concrete and then sent out, it can effectively avoid the pipe blocking phenomenon.





Technology parameter



Item

HBT-60



Max. Theoretical  Throughput(m3/h)

60

Max. Pumping Pressure(MPa)

13/15/16

Max.Theoretical Vertical Conveying Distance(m)

190

Max.Theoretical Horizontal Conveying Distance(m)

800

Max. Aggregate Diameter(mm)

50

Conveying Pipe Radius(mm)

150

Conveying Cylinder Bore X Piston Stroke(mm)

200*1650

Hydraulic Oil Tank Capacity(L)

580

Feeding Height(mm)

1420

Hopper Capacity(m3)

0.68

Power(kw)

90

Dimension(LengthΧWidthΧHeight)(mm)

6000*2160*2600

Product Display









Our Services



Company Information

History:

With more than 30 years development, our company has become one of the leading professional manufacturers and exporters of Construction Machinery in China. Till now, the factory area covering reaches 120,000m2 and have about 1000 person, including engineers, workers, sales, and service people.

Certificates:

We have got certificate ISO9001:2000 and passed SGS test. At present, our products are popular at home and abroad.

Our Markets:

Holding high quality products and honest operation as tenets, we have developed international market very well, such as Russia, Southeast Asia, Central Asia, Mid-East, South Africa, America, etc, more than twenty countries and regions.







Low price of concrete pump dimensions concrete pump for sale in korea!
