Portable concrete batching plant simple concrete batching plant

FOB Reference Price:Get Latest Price
US $10,000-35,000 / Set | 1 Set/Sets Portable concrete batching plant simple concrete batching plant (Min. Order)
Supply Ability:
100 Set/Sets per Month Portable concrete batching plant simple concrete batching plant
Port:
China main port
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Power Type:
Electric
Place of Origin:
Henan, China (Mainland)
Brand Name:
AIMIX
Model Number:
YHZS35
Power(W):
60kw
Dimension(L*W*H):
19.8m*8.2m*8.5m
Weight:
15T
Certification:
CE ISO
Warranty:
12 Months
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
Portable concrete batching plant simple concrete batching plant
Capacity:
35m3/h
Discharging Height:
3800mm
Main mixer:
JS750
Batching machine:
PLD 1200
Max. Aggregate:
80mm
Capacity of Aggregate Bin:
2*8m3
General Power:
60kw
Application:
Building Works
Color:
Request
Packaging & Delivery
Packaging Details
Standard packing or as request
Delivery Time
Shipped in 23 days after payment

Portable concrete batching plant  simple concrete batching plant

Product Description

Portable concrete batching plant  simple concrete batching plant include material storage, weighing, transportation, mixing, discharge and automatic control system .

Advantage features

1. It is composed of the systems of material supply, weighing, mixing and electric control;

2.Its discharge height is 3.8m, and it can mix various types of concrete;

3.With the loader to feed material, it can store four types of aggregates at the same time and also with two cement silos and their respective screw conveyor;

4.With electronic scales to measure and the mixing host is twin-horizontal-axis type;







Technology parameter



Model

YHZS35

Rated Productivity

35m3/h

Main Mixer

JS750

Batching Unit

PLD1200

Max. Aggregate Diameter

80mm

Discharging Height

3.8m

Capacity of Aggregate Bin

2X8m3

Aggregate Conveying Mode

Flat Bet Conveyor

Aggregate Weighing Precision

220000Kg ±2%

Cement Weighing Precision

450Kg ±1%

Water Weighing Precision

200Kg ±1%

Additive Weighing Precision

30Kg ±1%

General Power

60Kw

Total Weight

15T

Outline dimension (L*W*H)

                             19.8m*8.2m*8.5m

Product Display

Skip hoist concrete plant concrete mixing batching plant , it compose of  concrete mixer , batching machine, electric control system etc.


Successful Cases



Company Information



Our Services





If you are interested in our product, please contact us or leave massage,

we will reply you in 24 hours!

Portable concrete batching plant  simple concrete batching plant!!
