Quick Details

  • Condition: New
  • Power Type: Diesel
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: AIMIX
  • Model Number: HBT-40SR
  • Power(W): 56kw
  • Weight: 4500kg
  • Dimension(L*W*H): 5500*2000*2350 mm
  • Certification: ISO CE
  • Warranty: 12 Months
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Product name: 40m3/h concrete pump for sale price
  • Capacity: 40m3/h
  • Feeding Height: 1350mm
  • Hopper Capacity: 0.35m3/h
  • Max. Pumping Pressure: 8M pa
  • Max. Vertical Conveying Distance: 100m
  • Max. Conveying Distance: 450m
  • Max.Aggregate Diameter: 40mm
  • Application: Construction Engineering
  • Color: Customers' Requirement

Packaging & Delivery

Packaging Details standard packing
Delivery Time within 15 days after advanced payment

Constuction used price of 40m3/h concrete pump for sale

Product Description

 HBT-SR series diesel concrete pumps have been widely used in many construction areas such as Water conservancy, Electricity,Railway, Highway,Tunnel, Mine, National Defense, etc.They have also been exported to many countries and gotan excellent reputation .

Certification:

Our products have passed BV and ISO9001 International Quality System Certification and the mining concrete pumps have passed the Safety Certificate of Approval for Mining Products.







Technology parameter



Item

XHBT-20SR

XHBT-30SR

HBT-40SR

Max. Theoretical Throughput (m3/h)

20

30

40

Max. Pumping Pressure (M pa)

11

11

8

Max. Theoretical Vertical Conveying Distance (m)

160

160

100

Max. TheoreticalHorizontalConveying Distance (m)

600

600

450

Max.Aggregate Diameter (mm)

30

30

40

Slump (cm)

12-23

12-23

12-23

Conveying Pipe Radius (mm)

100A/80A

100A/80A

100A/80A

Conveying Cylinder Bore X Piston Stroke (mm)

140×1000

140×1000

180×1200

Hydraulic Oil Tank Capacity (L)

350

350

500

Feeding Height (mm)

1100

1200

1350

Hopper Capacity (m3)

0.35

0.35

0.35

Diesel Motor Model

R4105D2

R4105D7

WEICHAI DEUTZ

Power of DieselMotor (kw

46

61.6

56

Dimension (Length x Width x Weight) (mm)

5000*1700*2100

4450*1680*1950

5500*2000*2350

 Total Weight (kg)

3000

3050

4400

Advantages

1.The use of dual-pump, double-loop open hydraulic system, the main pump oil and S valve swing oil circuit independent of each other, the system is simple, component life extension, higher reliability, and easy to fault diagnosis and exclusion

2.With anti-pump function, which will help eliminate the block failure, and a short time to stop waiting for material.

3. The use of advanced S pipe distribution valve, can automatically compensate for wear and tear, sealing performance.

4.The use of wear-resistant alloy glasses and floating cutting ring, long service life. Glasses up to a maximum life of more than 30,000 square meters.

6.Automatic centralized lubrication system to ensure that the operation of the machine to be effective lubrication.

Main parts

 Some parts of concrete pump photos:



Packaging & Shipping



Company Information

History:

With more than 30 years development, our company has become one of the leading professional manufacturers and exporters of Construction Machinery in China. Till now, the factory area covering reaches 120,000m2 and have about 1000 person, including engineers, workers, sales, and service people.

Certificates:

We have got certificate ISO9001:2000 and passed SGS test. At present, our products are popular at home and abroad.

Our Markets:

Holding high quality products and honest operation as tenets, we have developed international market very well, such as Russia, Southeast Asia, Central Asia, Mid-East, South Africa, America, etc, more than twenty countries and regions.

\





Constuction used price of 40m3/h concrete pump for sale!!

welcome consulting!
